The Da Ros Tray Filler RC7-TR5N-M delivers fast, uniform tray filling and is an ideal solution for nurseries looking to streamline production. Designed for efficiency and consistency, this machine handles trays and pots in shuttle trays with reliable, uniform results.

Its electronically controlled system allows operators to fine-tune the speed of the soil distributor, conveyor belt and vibration to achieve the desired substrate density. Excess soil is automatically recovered and returned to the main hopper via an integrated return conveyor, keeping the process clean and reducing waste.

The RC7-TR5N-M can feed directly into seeding or transplanting machines, eliminating manual tray handling and storage while improving overall workflow efficiency. A smart, scalable solution for nurseries focused on increasing productivity and reducing labour.

KEY FEATURES

• Production capacity up to 600 trays/hour
• Fast, uniform tray filling for nurseries
• Electronically controlled speed adjustment for soil distributor, belt and vibration
• Adjustable substrate density control
• Automatic excess soil recovery system
• Direct integration with seeding and transplanting lines
• Reduces manual handling and improves productivity

MACHINE COMPOSITION

• Soil hopper
• Tray transport belt
• Vibrator
• Filling head
• Rotating brush group
• Bottom belt to recover excess soil

ACCESSORIES

• Tray templates for holding loose pots inside carry trays
• Optional wheel set for mobility
• Air blowing pipes for tray cleaning

TECHNICAL DATA

• Hopper capacity: 700 / 1200 / 1800L
• Maximum tray size: 600 x 400 x 130mm
• Installed power: 2.7kW, 400V, 3PH+N+E, 50Hz
• Optional power input: 230V, single phase
• Weight: 680kg
